Part Number:WS412
Product Reviews:

Availability:

In Stock
Save 38%
RRP: £445.20 £275.00 (£229.17 Ex VAT)
Unit Quantity: Each
Description
SOMMER APERTO 868 LX garage door operator (Double doors)
  • For double garage doors (Maximum door width 6.0m wide).
  • Pulling force 800 N.
  • Includes 2 hand transmitters, and uses 'rolling code' technology for added security.
  • Opener for up and over retractable or sectional doors garage doors. Bow arm converter would be needed for canopy up and over doors; please see part number WS298.
Benefits:
  • Quick easy and safe to open.
  • Easy to install in a couple of hours. No complex wiring or electrician required as it plus directly into the mains.
  • Individually coded for your security.
Rest assured when you purchase an APERTO operator you are buying luxury, quality and reliability at an affordable price.
Fitting Instructions

WS412 Sommer Aperto 868 LX (Double Garage Doors) fitting instructions

Additional Info

Benefits & Reassurance
-quick, easy and safe to operate.
-individually coded for your security.
-reliable operation with a 868.8 MHz radio frequency.
-modern, ergonomic hand transmitter design in very small encapsulation.
-integrated antenna.
-simple programming of the hand transmitter by radio.
-pre-mounted drive for easy assembly.
-gentle running, opens and closes extremely quietly.

Increased security
-extremely safe against unauthorised entry! The “Rolling Code System” changes automatically each time the operator is activated.
-fully automatic power sensing.
-door status sensing when a warning light is connected.
-the self locking motor ensures protection against unauthorised entry or power failure.
-connection facilities for safety devices, e.g. light barrier (photo cell), warning light and safety edge (available as accessories).

Quality
-innovative drive system provides extremely quiet running without wear.
-minimum space requirement due to compact design.
-“Made in Germany”.
-24 months warranty.
-TÜV, CE and type approved under European radio regulations.
-low maintenance technology.

Technology summary

APERTO 868 LX
Mains connection    230 V, 50/60 Hz
Capacity    80 – 450 W
Capacity with nominal traction power    230 W / 400 N
Traction / thrust force    50 – 800 N (5 – 80 kp)
Max. mechanism operation speed    0.16 m/s
Temperature range    -20°C / + 50°C
Lighting    24 V / 21 W
Packing length    1,080 mm
Overall length    3,500 mm
Weight including packaging    17 kg
Travel length    2,550 mm
Door type    sectional door wing opening door retractable door canopy door
Max. door height Swing door    2,550 mm 3,350 mm
Max. door height Folding door    2,300 mm 3,100 mm
Max. door width    6,000 mm
Min. height    35 mm
Remote control    868.8 MHz
Coding    Rolling Code
Number of radio channels    2
