Sommer Aperto 868 L (Single Garage Doors)
Availability:
In Stock- For single garage doors (Maximum door width 4.2m wide).
- A pulling force 550 N.
- Includes 2 hand transmitters, and uses 'rolling code' technology for added security.
- Opener for up and over retractable or sectional doors garage doors. A bow arm converter would be needed for a canopy-style up-and-over door.
- Quick, easy and safe to open.
- Easy to install in a couple of hours. No complex wiring or electrician is required as it plugs directly into the mains.
- Individually coded for your security.
Note: For doors without an alternate point of entry, an emergency release device will be required. This will allow the door to override the electric operator to open the door in the event of a power cut.
Rest assured when you purchase an APERTO operator you are buying luxury, quality and reliability at an affordable price.
Benefits & Reassurance
-quick, easy and safe to operate.
-individually coded for your security.
-reliable operation with a 868.8 MHz radio frequency.
-modern, ergonomic hand transmitter design in very small encapsulation.
-integrated antenna.
-simple programming of the hand transmitter by radio.
-pre-mounted drive for easy assembly.
-gentle running, opens and closes extremely quietly.
Increased security
-extremely safe against unauthorised entry! The “Rolling Code System” changes automatically each time the operator is activated.
-fully automatic power sensing.
-door status sensing when a warning light is connected.
-the self locking motor ensures protection against unauthorised entry or power failure.
-connection facilities for safety devices, e.g. light barrier (photo cell), warning light and safety edge (available as accessories).
Quality
-innovative drive system provides extremely quiet running without wear.
-minimum space requirement due to compact design.
-“Made in Germany”.
-24 months warranty.
-TÜV, CE and type approved under European radio regulations.
-low maintenance technology.
Technology summary
APERTO 868 L
Capacity 60 – 220 W
Traction / thrust force 50 – 550 N (5 – 55 kp)
Max. mechanism operation speed 0.16 m/s
Temperature range -20°C / +50°C
Lighting 24 V / 21 W
Packing length 1,080 mm
Overall length 3,500 mm
Weight including packaging 17 kg
Travel length 2,550 mm
Door type sectional door wing opening door retractable door canopy door
Max. door height Swing door 2,550 mm 3,350 mm
Max. door height Folding door 2,300 mm 3,100 mm
Max. door width 4,200 mm
Min. height 35 mm
Remote control 868.8 MHz
Coding Rolling Code
Number of radio channels 2
